Product Details
- Size: 7.5806
- Place of Origin: China
- Brand Name: Baoli
- Model Number: KB-series 3.5T (Diesel)
- Weight: 4750.000 kg
shing mark | Manufacturer | BAOLI | BAOLI | BAOLI | BAOLI | BAOLI | BAOLI | BAOLI | BAOLI | BAOLI | BAOLI | |
Model | KB15 | KB18 | KB20 | KB25 | KB25 | KB30 | KB30 | KB30 | KB35 | KB35 | ||
Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | Diesel | ||
Drive Seated | Seated | Seated | Seated | Seated | Seated | Seated | Seated | Seated | Seated | Seated | ||
Rated capacity/rated load | kg | 1500 | 1800 | 2000 | 2500 | 2500 | 3000 | 3000 | 3000 | 3500 | 3500 | |
Load centre distance | mm | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | |
Axle centre to fork face | mm | 435 | 435 | 435 | 484 | 484 | 484 | 484 | 484 | 484 | 484 | |
Wheel base | mm | 1500 | 1500 | 1500 | 1700 | 1700 | 1700 | 1700 | 1700 | 1700 | 1700 | |
Weight | Service weight | kg | 3060 | 3210 | 3280 | 3950 | 3960 | 4400 | 4260 | 4320 | 4880 | 4700 |
laden front/rear | kg | 3840/700 | 4330/680 | 4540/700 | 6340/610 | 5980/680 | 6610/580 | 6460/800 | 6460/800 | 7300/1100 | 7080/1140 | |
unladen front/rear | kg | 1380/1660 | 1340/1870 | 1320/1960 | 1880/2250 | 1680/2280 | 1820/2640 | 1700/2560 | 1700/2600 | 1640/3240 | 1480/3240 | |
Wheels | Tyres PN=(Pneumatic) | PN | PN | PN | PN | PN | PN | PN | PN | PN | PN | |
Tyre size,front | 6.5-10-14PR | 6.5-10-14PR | 6.5-10-14PR | 28*9-15-14PR | 28*9-15-14PR | 28*9-15-14PR | 28*9-15-14PR | 28*9-15-14PR | 28*9-15-14PR | 28*9-15-14PR | ||
Tyre size,rear | 5-8-10PR | 5-8-10PR | 5-8-10PR | 6.5-10-10PR | 6.5-10-10PR | 6.5-10-10PR | 6.5-10-10PR | 6.5-10-10PR | 6.5-10-10PR | 6.5-10-10PR | ||
Front Track Width | b10(mm) | 940 | 940 | 940 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | |
Rear Track Width | b11(mm) | 920 | 920 | 920 | 970 | 970 | 970 | 970 | 970 | 970 | 970 | |
Basic dimensions | Tilt of mast/fork carriage forward/backward | α/β(°) | 6°/12° | 6°/12° | 6°/12° | 6°/12° | 6°/12° | 6°/12° | 6°/12° | 6°/12° | 6°/12° | 6°/12° |
Height,mast lowered | mm | 2002 | 2002 | 2002 | 2040 | 2040 | 2035 | 2035 | 2035 | 2180 | 2180 | |
Free lift | mm | 128 | 128 | 128 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | |
Lift height | mm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | |
Height,mast extended | mm | 4040 | 4040 | 4040 | 4050 | 4050 | 4273 | 4273 | 4273 | 4273 | 4273 | |
Height of overhead guard (cabin) | mm | 2065 | 2065 | 2065 | 2108 | 2108 | 2108 | 2108 | 2090 | 2108 | 2108 | |
Seat height | mm | 1010 | 1010 | 1010 | 1085 | 1085 | 1085 | 1085 | 1070 | 1085 | 1085 | |
Drawbar height | mm | 220 | 220 | 220 | 300 | 300 | 300 | 300 | 300 | 300 | 300 | |
Overall length | mm | 3432 | 3466 | 3490 | 3735 | 3735 | 3785 | 3785 | 3780 | 3885 | 3885 | |
Length to face of forks | mm | 2362 | 2396 | 2420 | 2665 | 2665 | 2715 | 2715 | 2710 | 2815 | 2815 | |
Overall width | mm | 1140 | 1140 | 1140 | 1225 | 1225 | 1225 | 1225 | 1236 | 1225 | 1225 | |
Fork dimensions DIN ISO 2331 | mm | 35/120/1070 | 35/120/1070 | 40/122/1070 | 40/122/1070 | 40/122/1070 | 45/125/1070 | 45/125/1070 | 45/125/1070 | 50/125/1070 | 50/125/1070 | |
Fork carriage ISO 2328,class/type A,B | A | A | A | A | A | A | A | A | A | A | ||
Fork-carriage width | mm | 1040 | 1040 | 1040 | 1040 | 1040 | 1100 | 1100 | 1100 | 1100 | 1100 | |
Ground clearance,laden,below mast,laden/unladen | mm | 110 | 110 | 110 | 135 | 135 | 135 | 135 | 135 | 135 | 135 | |
Ground clearance,centre of wheelbase,laden/unladen | mm | 105 | 105 | 105 | 140 | 140 | 140 | 140 | 140 | 140 | 140 | |
Working aisle width | mm | 3795 | 3815 | 3835 | 4124 | 4124 | 4144 | 4144 | 4144 | 4224 | 4224 | |
Working aisle width | mm | 3995 | 4015 | 4035 | 4324 | 4324 | 4344 | 4344 | 4344 | 4424 | 4424 | |
Turning radius | mm | 2160 | 2180 | 2200 | 2440 | 2440 | 2460 | 2460 | 2460 | 2540 | 2540 | |
Turning Point Minimum Distance from the Truck Center Line | mm | 601.5 | 601.5 | 601.5 | 810 | 810 | 810 | 810 | 810 | 810 | 810 | |
Performance data | Travel speed,laden/unladen | km/h | 16.3/16.31 | 15.7/15.9 | 14.8/15.2 | 15/16.2 | 18.5/20 | 16.5/17 | 18.5/20 | 18.9/19.5 | 16/17 | 18.5/20 |
Lift speed,laden/unladen | m/s | 505.5/716.56 | 445.16/726.98 | 389.44/645.16 | 498/658 | 320/530 | 522/597 | 400/430 | 436.1/502.5 | 561/588 | 380/430 | |
Lowering speed,lade/unladen | m/s | 375.78/396.48 | 405.04/416.28 | 467.53/454.78 | 485/370 | 475/360 | 479/393 | 450/400 | 449.8/475.4 | 491/398 | 480/400 | |
Drawbar pull,lade unladen | kN | 11.5/10.7 | 11.5/10.7 | 10.7/10.7 | 15/10 | 15/10 | 15/10 | 15/10 | 15/10 | 16/10 | 17/10 | |
Gradeability,laden/unladen | % | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 15 | 15 | |
Service brake | Mechanical/Hydraulic | |||||||||||
Drive | Engine manufacturer | ISUZU C240 | ISUZU C240 | ISUZU C240 | Mitsubishi S4S-474 | WeiChai WP2.7 | Mitsubishi S4S-474 | WeiChai WP2.7 | ISUZU C240 | Mitsubishi S4S-474 | WeiChai WP2.7 | |
Engine Power in compliance with ISO 1585 | Kw | 35.4 | 35.4 | 35.4 | 35.3 | 40 | 35.3 | 40 | 35.4 | 35.3 | 40 | |
Rated Number of Revolution | /min | 2500 | 2500 | 2500 | 2250 | 2650 | 2250 | 2650 | 2500 | 2250 | 2650 | |
cylinder Number/displacement | cm³ | 4/2369 | 4/2369 | 4/2369 | 4/3331 | 4/2670 | 4/3331 | 4/2670 | 4/2369 | 4/3331 | 4/2670 | |
On-board voltage | V | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | |
Other | Volume fuel tank | l/kg | 45/37 | 45/37 | 45/37 | 45/37 | 52/45 | 45/37 | 52/45 | 45/37 | 45/37 | 52/45 |
Sound pressure level | dB(A) | 107 | 107 | 107 | 109 | - | 109 | - | 89.4 | 109 | - | |
Drawbar,model/Type DIN 15170 |
